Metal Meter Box- 2 Hour Fire Rated

The 2-Hour Fire Rated Metal Faced Meter Box is a robust and secure access solution designed to provide safe access to utility meters, electrical equipment, and service installations while maintaining the fire integrity of the wall. Manufactured from high-quality steel, this access panel is ideal for commercial, residential, healthcare, education, and public sector buildings where certified fire protection and durability are required.

R16/120/MD/PF/L34A

£253.19 – £305.99

Panel Size

Clear

Need a Bespoke Size?

Product Description

The 2 Hour Fire Rated Metal Faced Meter Box is designed for secure wall installations, providing protected access to utility meters and associated services while maintaining certified fire performance.
Features a durable single steel door with a 25mm picture frame for a clean, professional finish.
Fitted with an 8mm triangular quarter turn lock for secure access by authorised personnel and quick operation during maintenance.
Finished in a hard-wearing RAL 9010 White (30% Gloss) powder coating for excellent durability and corrosion resistance.
Manufactured with a standard 70mm frame depth, with alternative frame depths available upon request.
The first dimension stated represents the hinge side, while the published sizes correspond to the structural opening plus 5mm installation clearance.
Independently tested to provide up to 2 hours fire resistance for wall applications.

Product Features

The 2 Hour Fire Rated Metal Faced Meter Box offers a robust and secure solution for protecting utility meter installations in fire-rated walls. Combining durable steel construction with a 25mm picture frame, triangular quarter turn lock and high-quality powder-coated finish, it provides reliable fire performance, long-lasting durability and a professional appearance for residential, commercial and industrial applications.

Data Sheet One Certificate

Product Specifications

Product Type

Metal Faced Meter Box

Fire Rating

2-Hour Fire Rated

Material

Steel (Metal Faced)

Door Type

Single Metal Door

Frame Style

25mm Wide Picture Frame

Lock Type

8mm Triangular Electrical Cabinet Quarter Turn Lock

Finish

Powder Coated RAL 9010 White, 30% Gloss

Standard Frame Depth

70mm (Other Depths Available Upon Request)

Metal Meter Box- 2 Hour Fire Rated

Product Specifications

Certified for Safety & Performance
